Product ID : WS-C2960-24TT-L
Product Tags :
Product Description

Manufacturer Part#: Cisco WS-C2960-24TT-L

WS-C2960-24TT-L 24 10/100 Ethernet ports and 2 10/100/1000-TX uplink port 1 rack unit (RU) fixed configuration switches To provide entry-level enterprise intelligence service Installation of the LAN mirror, 24 Ethernet ports and 10/100 2 double medium uplink port (each uplink port has a 10/100/1000 Ethernet port and an SFP Gigabit Ethernet port, you can use only one port at a time)

WS-C2960-24TT-L Description
Cisco Catalyst 2960 Series Intelligent Ethernet Switches are a new family of fixed-configuration standalone devices that provide desktop Fast Ethernet and Gigabit Ethernet connectivity, enabling enhanced LAN services for entry-level enterprise, mid-market, and branch office networks. The Catalyst 2960 Series offers integrated security, including network admission control (NAC), advanced quality of service (QoS), and resiliency to deliver intelligent services for the network edge.

Cisco WS-C2960-24TT-L Catalyst 2960-24TT - switch - 24 ports - Managed - rack-mountable
Part Code: WS-C2960-24TT-L
•Manufacturer: Cisco
•Device Type: Switch - 24 ports - Managed
•Enclosure Type: Rack-mountable 1U
•Interfaces: Fast Ethernet
•Ports: 24 x 10/100 + 2 x 10/100/1000

WS-C2960-24TT-L Parameter:
Catalyst 2960 Series Intelligent Ethernet Switches with LAN Base software providing enhanced LAN services

WS-C2960-24TT-L Supply:
In stock and ready to ship
WS-C2960-24TT-L Price:
GET A QUOTE from Sea Tel International Co., Limited

WS-C2960-24TT-L Product Details
Device Type Switch - 24 ports - Managed
Enclosure Type Rack-mountable 1U
Interfaces Fast Ethernet
Ports 24 x 10/100 + 2 x 10/100/1000
Performance Switching capacity : 32 Gbps
Forwarding performance (64-byte packet size) : 6.5 Mpps
MAC Address Table Size 8K entries
Remote Management Protocol SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP)
Power AC 120/230 V ( 50/60 Hz )

WS-C2960-24TT-L Dimensions
(WxDxH) 44.5 cm x 23.6 cm x 4.4 cm
Weight 3.63 kg
Manufacturer Warranty Limited lifetime warranty

WS-C2960-24TT-L Catalyst 2960 24 10/100 + 2 10/100/1000 Uplinks LAN-Base Image
Manufacturer Part#   WS-C2960-24TT-L
UPC Code:   882658044113
Product Type: Ethernet Switch
Power Source: Power Supply
Total Number of Network Ports: 24
Limited Warranty: Lifetime
Product Family: Catalyst 2960
WS-C2960-24TT-L Product Name Catalyst 2960 24 10/100 + 2 10/100/1000 Uplinks LAN-Base Image
Product Type Ethernet Switch
Manageable Yes
Ethernet Technology Fast Ethernet
Number of Network (RJ-45) Ports 24
Media Type Supported Twisted Pair
Total Number of Network Ports 24
Height 1.7"
Width 17.5"
Depth 9.3"
Product Series 2960
Product Model 2960-24TT
Network Technology 10Base-T
WS-C2960-24TT-L Product Line Catalyst
Input Voltage 110 V AC
220 V AC
WS-C2960-24TT-L Layer Supported 2
Twisted Pair Cable Standard Category 5
Redundant Power Supply Yes
Uplink Port Yes

WS-C2960-24TT-L Management Cisco Network Assistant
CiscoWorks Support
Device manager
Cisco Express Setup
CiscoView application

WS-C2960-24TT-L Cisco Network Assistant Software
Trivial File Transfer Protocol (TFTP) reduces the cost of administering software upgrades by downloading from a centralized location
Network Timing Protocol (NTP) provides an accurate and consistent timestamp to all intranet switches
Cisco IOS CLI support provides a common user interface and command set with all Cisco routers and Cisco Catalyst desktop switches
Cisco Service Assurance Agent (SAA) support facilitates service-level management throughout the LAN
Switching Database Manager templates for security and QoS allow administrators to easily adjust memory allocation to the desired features based on deployment-specific requirements
VLAN trunks can be created from any port using standards-based 802.1q tagging
Up to 255 VLANs per switch or stack and up to 128 spanning-tree instances per switch are supported.
Four thousand VLAN IDs are supported
Voice VLAN simplifies telephony installations by keeping voice traffic on a separate VLAN for easier administration and troubleshooting
Cisco VTP supports dynamic VLANs and dynamic trunk configuration across all switches
SNMP v1, v2c, and v3 and Telnet interface support delivers comprehensive in-band management, and a CLI-based management console provides detailed out-of-band management
Cisco Discovery Protocol Versions 1 and 2 help enable a CiscoWorks network-management station for automatic switch discovery
WS-C2960-24TT-L Power Source Power Supply
Product Family Catalyst 2960
Additional Information 64 MB DRAM
32 MB flash memory
LAN Base Image installed
Configurable up to 8000 MAC addresses
Configurable up to 255 IGMP groups
Cisco Catalyst 2960-24TT: 282,416 hr
Superior Redundancy for Fault Backup
Integrated Cisco IOS Software Features for Bandwidth Optimization
Advanced QoS
Granular Rate Limiting
Networkwide Security Features
Cisco WS-C2960-24TT-L — Catalyst 2960 Series 24-port Ethernet 10/100 + 2x 10/100/1000 TX uplinks
Brand: Cisco Systems
Series: Catalyst 2960 Series
Model: WS-C2960-24TT-L
Product Type: Ethernet Switch (LAN Base image)
Form Factor: 1U / Rackmount / Fixed
Condition: Brand New / Sealed
Lead time: 4-5 days

WS-C2960-24TT-L Technical Specs:
Ports: 24
Speed: 10/100 Mbps
Forwarding Bandwidth:  16 Gbps
Switching Bandwidth:  32 Gbps
Flash Memory: 32MB
Memory DRAM:  64MB
Max VLANs:  255
VLAN IDs: 4,000
Maximum Transmission Unit (MTU):  Up to 9000 bytes
Forwarding Rate:  6.5 mpps
Unicast MAC Addresses: 8000
IPv4 IGMP Groups:  255
Mean Time Between Failure (MTBF): 407,707 hours
Remote Management Protocol:  SNMP 1 , SNMP 2 , SNMP 2c , SNMP 3 , RMON 1 , RMON 2 , RMON 3 , RMON 9 , Telnet , TFTP , SSH , HTTP , HTTPS ,
Compliant Standards: IEEE 802.1ab (LLDP) , IEEE 802.1D , IEEE 802.1p , IEEE 802.1Q , IEEE 802.1s , IEEE 802.1w , IEEE 802.1x , IEEE 802.2 , IEEE 802.3 , IEEE 802.3ab , IEEE 802.3ad (LACP) , IEEE 802.3ah , IEEE 802.3u , IEEE 802.3x , IEEE 802.3z
Control Features:  This Cisco Switch Model (WS-C2960-24TT-L) features twenty four (24) Ethernet ports with 10/100BASE-TX desktop connectivity, along with two (2) 10/100/1000BASE-T uplinks.

•Automatic QoS (AutoQoS)
•Stacking Master configuration management & Cisco FlexStack
•Dynamic Host Configuration Protocol (DHCP) autoconfiguration
•Auto-negotiation on all 24 ports
•Dynamic Trunking Protocol (DTP)
•Port Aggregation Protocol (PAgP)
•Link Aggregation Control Protocol (LACP) for Ethernet channeling
•Automatic media-dependent interface crossover (MDIX)
•Unidirectional Link Detection Protocol (UDLD) & Aggressive UDLD
•Switching Database Manager (SDM) templates for access, routing, and VLAN deployment
•Local Proxy Address Resolution Protocol (ARP)
•Internet Group Management Protocol (IGMP) Snooping for IPv4 and IPv6 MLD v1 and v2
•Multicast VLAN Registration (MVR)
•Per-port broadcast, multicast, and unicast storm control
•Voice VLAN helps simplify telephony installations
•Cisco VLAN Trunking Protocol (VTP) supports dynamic VLANs
•Remote Switch Port Analyzer (RSPAN)
•Embedded Remote Monitoring (RMON) for traffic management, monitoring, and analysis
•Cisco FlexStack stacking support is optional for the Cisco WS-C2960-24TT-L.
•Layer 2 traceroute eases troubleshooting
•Trivial File Transfer Protocol (TFTP)
•Network Timing Protocol (NTP)

WS-C2960-24TT-L Dimensions:
Height: 1.73 inches   (4.4 cm)
Width: 17.7 inches   (45 cm)
Depth: 9.52 inches   (23.6 cm)
Weight: 8.0 lbs.  (3.6 kg)

All series of NEW and USED Cisco Catalyst Switches available in our company
Express 500, 2950, 2918,2960, 3550, 3560, 3560E, 3750, 3750E, 4900, 4500, 6500 and 3750 Metro series
