HWIC-AP-AG-B

Manufacturer Part#: Cisco HWIC-AP-AG-B
HWIC-AP-AG-B Cisco Wireless Module

HWIC-AP-AG-B Wi-Fi - IEEE 802.11a/b/g - 54Mbps - Wireless Module

HWIC-AP 802.11a/b/g is a Wireless LAN interface card in the HWIC (High-Speed WAN Interface Card) form factor providing integrated Access Point functionality in the Cisco 1800 (Modular), Cisco 2800, and Cisco 3800 Integrated Services Routers. Enterprise branch office and small-to-medium business customers can run concurrent services of Layer 3 routing, security, Layer 2 switching and now IEEE 802.11 wireless LAN functionality in a single platform. This combination offers ease of configuration, deployment, and management while delivering high performance, security and rich set of services.

Cisco HWIC-AP-AG-B General Information:
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Name: 802.11 a/b/g High Speed Wan Interface Card
Product Type: Wireless Module

Cisco HWIC-AP-AG-B Wireless Specifications:
Wireless Technology: Wi-Fi - IEEE 802.11a/b/g
Antenna: 2 x Swivel Dipole Antenna External with RP-TNC Connector
Antenna Range: 300 ft@ 54Mbps Outdoors
Antenna Range: 80 ft@ 54Mbps Indoors
Antenna Range: 300 ft@ 1 Mbps Indoors
Antenna Range: 2000 ft@ 1 Mbps Outdoors
Frequency Band/Bandwidth: 5.15 GHz to 5.35 GHz IEEE 802.11a UNII Band America (FCC)
Frequency Band/Bandwidth: 2.41 GHz to 2.46 GHz IEEE 802.11b/g ISM Band America (FCC)
Frequency Band/Bandwidth: 5.72 GHz to 5.82 GHz IEEE 802.11a UNII Band America (FCC)
Transmission Speed: 54Mbps
Transmission Speed Details: 54Mbps Auto-fallback IEEE 802.11a/g
Transmission Speed Details: 11Mbps Auto-fallback IEEE 802.11b
Transmission Speed Details: 1Mbps IEEE 802.11b
Transmission Speed Details: 6Mbps IEEE 802.11a/g

HWIC-AP-AG-B Wireless Security:
•IEEE 802.1x Security
•WEP keys of 40 bits and 128 bits
•WPA TKIP
•LEAP & EAP-FAST
•Preshared key (PSK)
•MAC address and standard 802.11 authentication mechanisms

HWIC-AP-AG-B Modulation:
802.11a:
•DBPSK - 1 Mbps
•DQPSK - 2 Mbps
•CCK - 5.5 & 11 Mbps
•BPSK - 6 & 9 Mbps
•QPSK - 12 &18 Mbps
•16-QAM - 24 & 36 Mbps
•64-QAM - 48 & 54 Mbps

802.11b/g:
•BPSK - 6 & 9 Mbps
•QPSK - 12 &18 Mbps
•16-QAM - 24 & 36 Mbps
•64-QAM - 48 & 54 Mbps

Cisco HWIC-AP-AG-B Management & Protocols:
Security Features: AES
Security Features: RADIUS
Security Features: AAA RADIUS Server per SSID

Cisco HWIC-AP-AG-B Physical Characteristics:
Dimensions: 0.76 Height x 3.09 Width x 4.9 Depth
Weight: 5.76 oz - With HWIC Module and Swivel Dipole Antennas

Cisco HWIC-AP-AG-B Miscellaneous:
•Spare Product
•SSIDs: 6
•Wireless VLANs: 6
•SNMP v1, v2, and v3 support
•Telnet interface support
•Support is provided by the CiscoWorks LAN Management Solution
