WPS11

Manufacturer Part#: Cisco WPS11
WPS11 Cisco Wireless Print Server

WPS11 - ver. 3 Wireless Print Server 1 x 10/100Base-TX Network, 1 x Parallel - Wi-Fi - IEEE 802.11b - External

The EtherFast Wireless PrintServer provides an easy solution for placing a printer on your wireless network. Don't waste valuable system and network resources or create printing bottlenecks by attaching a printer to one of the nodes on the network. Instead, place a printer anywhere in range of your wireless devices using this con-venient device. You will save space and time, and increase your net-work performance as well.

Cisco WPS11 General Information:
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Name: WPS11 ver. 3 Wireless Print Server
Product Type: Wireless Print Server

Cisco WPS11 Wireless Specifications:
Wireless Technology: Wi-Fi - IEEE 802.11b
Frequency Band/Bandwidth: 2.4 GHz
Antenna Range: Up to 100 ft@ 11Mbps Indoors
Antenna Range: Up to 165 ft@ 5.5Mbps Indoors
Antenna Range: Up to 230 ft@ 2Mbps Indoors
Antenna Range: Up to 300 ft@ 1 Mbps Indoors
Antenna Range: Up to 500 ft@ 11Mbps Outdoors
Antenna Range: Up to 885 ft@ 5.5Mbps Outdoors
Antenna Range: Up to 1300 ft@ 2Mbps Outdoors
Antenna Range: Up to 1500 ft@ 1 Mbps Outdoors

WPS11 Transmission Speed: 11Mbps
Transmission Speed Details: 11Mbps Auto-fallback IEEE 802.11b
Transmission Speed Details: 5.5Mbps Auto-fallback IEEE 802.11b
Transmission Speed Details: 2Mbps Auto-fallback IEEE 802.11b
Transmission Speed Details: 1Mbps IEEE 802.11b

Cisco WPS11 Interfaces/Ports:
Interfaces/Ports: 1 x RJ-45 10/100Base-TX Network
Interfaces/Ports: 1 x DB-25 Parallel

Cisco WPS11 Media & Performance:
Connectivity Media: 10/100Base-TX Category 5 UTP
Data Transfer Rate: 10Mbps Ethernet Half-duplex
Data Transfer Rate: 100Mbps Fast Ethernet Half-duplex
Data Transfer Rate: 20Mbps Ethernet Full-duplex
Data Transfer Rate: 200Mbps Fast Ethernet Full-duplex
Data Transfer Rate: 1.5Mbps Parallel

Cisco WPS11 Management & Protocols:
Management:
Easy-to-Use Built-In Remote Management Utility.
Easy-to-Use Built-In Remote Management Utility.

WPS11 Protocols: CSMA/CD

Cisco WPS11 Memory:
Memory: 512KB Flash Memory
Memory: 256KB Buffer Memory

Cisco WPS11 Controls/Indicators:
Controls: Reset Switch

WPS11 Status Indicators:
LAN
WLAN
ACT
Err
LAN
WLAN
ACT
Err

Cisco WPS11 Environmental Conditions:
Temperature: 32 degrees F (0.0 degrees C) to 104 degrees F (40.0 degrees C) Operating
Temperature: -4 degrees F (-20.0 degrees C) to 158 degrees F (70.0 degrees C) Storage
Humidity: 10% to 85% Non-condensing Operating
Humidity: 5% to 90% Non-condensing Storage

Cisco WPS11 Physical Characteristics:
Form Factor: External
Dimensions: 1.18 Height x 3.74 Width x 4.76 Depth
