CISCO1801

Manufacturer Part#: Cisco  CISCO1801
CISCO1801 Cisco 1800 Series Router

CISCO1801 -

Cisco CISCO1801 Environmental Conditions:
Humidity: 10% to 85% Non-condensing Operating
Altitude: 10000 ft Operating
Thermal Dissipation: 153 BTU/h

Cisco CISCO1801 Physical Characteristics:
Compatible Rack Unit: 1U
Form Factor: Rack-mountable
Form Factor: Wall-mountable
Form Factor: Desktop
Dimensions: 1.73 Height x 12.5 Width x 9.5 Depth
Dimensions: 1.87 Height x 12.5 Width x 9.5 Depth
Weight: 6.1 lb

Cisco CISCO1801 Original Manufacturer Warranty:
Standard Warranty: 1 Year Limited

Cisco CISCO1801 Power Description:
Power Consumption: 50W Maximum

Cisco CISCO1801 Environmental Conditions:
Temperature: 0 degrees C (32.0 degrees F) to 40 degrees C (104.0 degrees F) Operating
Temperature: -25 degrees C (-13.0 degrees F) to 65 degrees C (149.0 degrees F) Non-operating
Humidity: 5% to 95% Non-condensing Non-operating

Cisco CISCO1801 General Information:
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Series: 1800
Product Name: 1801 Integrated Services Router
Product Type: Integrated Services Router

Cisco CISCO1801 Interfaces/Ports:
Number of Ports: 11
Fast Ethernet Port: Yes
ISDN Port: Yes
DSL Port: Yes
Interfaces/Ports: 1 x RJ-45 Auxiliary Management
Interfaces/Ports: 1 x RJ-45 Console Management
Interfaces/Ports: 1 x RJ-45 ISDN BRI (S/T) ISDN BRI (S/T) WAN
Interfaces/Ports: 1 x RJ-11 ADSL ADSL WAN
Interfaces/Ports: 1 x RJ-45 10/100Base-TX 10/100Base-TX WAN
Interfaces/Ports: 8 x RJ-45 10/100Base-TX 10/100Base-TX LAN

Cisco CISCO1801 Media & Performance:
Connectivity Media: Category 5 UTP 10/100Base-TX
Distance Support: 328.08 ft Category 5 UTP
Encryption Throughput: 40 Mbps

Cisco CISCO1801 Memory:
Standard Memory: 128MB
Maximum Memory: 384MB
Memory Technology: DRAM
Flash Memory: 32 MB

Cisco CISCO1801 Software:
Operating System:
Cisco IOS Software Release 12.3(8)YI Advance IP Services with IP Broadband feature set

Cisco CISCO1801 Power Description:
Input Voltage: 110V AC
Input Voltage: 220V AC
Input Voltage Range: 100V AC to 120V AC
Input Voltage Range: 200V AC to 240V AC
Input Current: 0.6 Ato 1.2 A
Frequency: 50 Hz or 60 Hz
