WS-X4648-RJ45-E

Manufacturer Part#: Cisco WS-X4648-RJ45-E=
Cisco WS-X4648-RJ45-E 4500E 48-Port Catalyst Switch Module

Cisco WS-X4648-RJ45V-E= Catalyst 4500 E-Series 48 Port Poe 802.3AF 10/100/1000RJ45

WS-X4648-RJ45-E The Cisco Catalyst 4500 Series offers two classes of line cards: classic and E-Series. Classic line cards provide 6 gigabits of switching capacity per slot. E-Series line cards increase the per slot switching capacity to 24 gigabits. This increase in per slot switching capacity with the E-Series line cards requires the Cisco Catalyst 4500 E-Series chassis and the Cisco Catalyst 4500 Series Supervisor Engine 6-E. Classic line cards may be deployed in both classic and E-Series chassis with either classic Cisco Catalyst 4500 Series supervisor engines or with the Supervisor Engine 6-E. With the Supervisor Engine 6-E, the classic line cards per slot switching capacity remains at 6 gigabits per slot. However, because of the centralized switching architecture of the Cisco Catalyst 4500, the classic line cards will adopt all of the new Supervisor Engine 6-E features such as eight queues per port, dynamic QoS, and hardware-based IPv6 routing. Please refer to the Supervisor Engine 6-E data sheet for more feature details. Classic line cards and E-Series line cards may be mixed and matched within a Cisco Catalyst 4500 E-Series chassis with no performance degradation: classic line cards will operate at 6 gigabits per slot, and E-Series line cards will operate at 24 gigabits per slot. Table 1 summarizes the chassis and supervisor support for both classic and E-Series line cards.

Cisco Catalyst 4500 Series Switches enable borderless networks, providing high-performance, mobile, and secure user experiences through Layer 2-4 switching. Enabling security, mobility, application performance, video, and energy savings over your network infrastructure, the Cisco Catalyst 4500 Switch supports resiliency, virtualization, and automation, further improving the ease of network use. Cisco Catalyst 4500 Series Switches provide borderless performance, scalability, and services with reduced total cost of ownership (TCO) and superior investment protection.

The Cisco Catalyst 4500 Switch WS-X4648-RJ45-E  delivers predictable and scalable high performance, with advanced dynamic quality of service (QoS) capabilities and configuration flexibility for deploying borderless networks. Integrated resiliency features in both hardware and software maximize network availability, helping to ensure workforce productivity, profitability, and customer success. Its centralized, innovative, and flexible system design helps ensure smooth migration to wire-speed IPv6 and 10 Gigabit Ethernet (GE). The forward and backward compatibility between generations of the Cisco Catalyst 4500 Series extends deployment life, providing exceptional investment protection, while reducing the (TCO).

The Cisco Catalyst 4500E Series is a high-performance, next-generation extension to the Cisco Catalyst 4500 Series. The E-Series is designed for a high-performance, mobile, and secure user experience with superior backward and forward compatibility, delivering exceptional investment protection for organizations of all sizes.

WS-X4648-RJ45-E Product Highlights
•24 gigabits per slot capacity
•48 ports
•10/100/1000 module (RJ-45)
•Bandwidth is allocated across eight 6-port groups, providing 3 Gbps per port group (2:1)
•L2-4 Jumbo Frame support (up to 9216 bytes)

WS-X4648-RJ45-E •Product Type: Supervisor Engine
•Cisco Catalyst 4500 E-Series 48-Port 802.3af PoE 10/100/1000 (RJ-45))
•24 gigabits per slot capacity , 48 ports
•10/100/1000 module (RJ-45)
•Cisco IOS Software Re

WS-X4648-RJ45-E General Specifications
Manufacturer Cisco
Manufacturer Part # WS-X4648-RJ45-E
Cost Central Item # 11051200
Product Description Cisco Catalyst 4500E Series Line Card - Switch - 48 x 10/100/1000 - plug-in module
Device Type Switch - 48 ports
Enclosure Type Plug-in module
Interfaces Gigabit Ethernet
Ports 48 x 10/100/1000
Features Flow control, half duplex mode, full duplex mode, Jumbo Frames support
Compliant Standards IEEE 802.3x
Approximate Dimensions (WxDxH) 14.3 in x 10.7 in x 1.2 in
System Requirements Cisco IOS 12.2(50)SG

WS-X4648-RJ45-E Extended Specifications
GeneralDevice Type Switch - 48 ports
Enclosure Type Plug-in module
Interfaces Gigabit Ethernet
Compatible Slots 1 x expansion slot
Ports 48 x 10/100/1000
Features Flow control, half duplex mode, full duplex mode, Jumbo Frames support
Compliant Standards IEEE 802.3x
Status Indicators Port status, link OK

WS-X4648-RJ45-E Expansion / ConnectivityInterfaces 48 x 1000Base-T - RJ-45

WS-X4648-RJ45-E Environmental ParametersMin Operating Temperature 32 °F
Max Operating Temperature 104 °F
Humidity Range Operating 10 - 90% (non-condensing)
Min Storage Temperature -40 °F
Max Storage Temperature 167 °F

WS-X4648-RJ45-E MiscellaneousMTBF 280,365 hours
Compliant Standards NEBS level 3, ETSI, CISPR 22 Class A, EN 60950, IEC950, UL 1950, VCCI Class A ITE, EN55024, EN55022 Class A, CSA 22.2 No. 60950, AS/NZS 3548, FCC Part 15 A

WS-X4648-RJ45-E Dimensions & WeightApproximate Width 14.3 in
Approximate Depth 10.7 in
Approximate Height 1.2 in

WS-X4648-RJ45-E Software / System Requirements
IOS Required Cisco IOS 12.2(50)SG

WS-X4648-RJ45-E General
Compatible Slots : 1 x expansion slot
Ports : 48 x 10/100/1000
Features : Flow control, half duplex mode, full duplex mode
Compliant Standards : IEEE 802.3x

WS-X4648-RJ45-E General Specifications
Manufacturer : Cisco
Manufacturer Part # : WS-X4648-RJ45-E
Cost Central Item # : 11051200
Product Description : Cisco Switching Module - Switch - 48 x 10/100/1000 - plug-in module
Device Type : Switch - 48 ports
Enclosure Type : Plug-in module
Ports : 48 x 10/100/1000
Features : Flow control, half duplex mode, full duplex mode
Compliant Standards : IEEE 802.3x
Approximate Dimensions (WxDxH) : 14.4 in x 10.5 in x 1.7 in
Approximate Weight : 4.9 lbs

WS-X4648-RJ45-E Description
The Cisco WS-X4648-RJ45V-E is a PoE implementation of Catalyst 4500 E-Series PoE line card.

WS-X4648-RJ45-E Product Details
Device Type Switch - 48 ports
Enclosure Type Plug-in module
Interfaces Gigabit Ethernet
Ports 48 x 10/100/1000 (PoE)
Power Over Ethernet (PoE) PoE
Compliant Standards IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP)
Dimensions (WxDxH) 36.2 cm x 27.3 cm x 3 cm
Designed For Catalyst 4503-E, 4506-E, 4507R-E, 4510R-E

Contact Sea Tel International for more information.
