VIP4-50

Manufacturer Part#: Cisco VIP4-50
VIP4-50 Interface & Line Card

VIP4-50 - cisco VPN and Security series module

The Versatile Interface Processor 4 (VIP4) for the high-end Cisco 7500 router series enables high-performance switching, and scalable LAN and WAN intelligent network services to meet the needs of high-performance applications. It provides over twice the distributed switching performance and twice the aggregate bandwidth of previous model VIPs, employs higher-capacity memory modules for rich IP services, and utilizes Error Correction Code (ECC) for increased system availability. The VIP4 serves as an ideal platform for enterprise and service-provider networks that require high performance and processing power to support service-enabled edge and core applications.

Cisco VIP4-50 General Information:
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Name: VIP4-50 Versatile Interface Processor
Product Type: Versatile Interface Processor

Cisco VIP4-50 Interfaces/Ports:
Interfaces/Ports Details: Not Applicable

Cisco VIP4-50 Media & Performance:
Connectivity Media: Not Applicable
Data Transfer Rate: Not Applicable

Cisco VIP4-50 Management & Protocols:
Management:
Simple Network Management Protocol (SNMP) agent V1 (RFCs 1155-1157)
Management Information Base (MIB) II (RFC 1213)
Simple Network Management Protocol (SNMP) agent V1 (RFCs 1155-1157)
Management Information Base (MIB) II (RFC 1213)

VIP4-50 Protocols: ATM

Cisco VIP4-50 Processor & Chipset:
Processor: 1 MIPS RM5000 250MHz

Cisco VIP4-50 Memory:
Memory: 64MB SDRAM Installed
Memory: 256MB SDRAM Upgradeable
Memory: 128MB SDRAM Upgradeable

Cisco VIP4-50 Environmental Conditions:
Temperature: 32 degrees F (0.0 degrees C) to 104 degrees F (40.0 degrees C) Operating
Temperature: -4 degrees F (-20.0 degrees C) to 149 degrees F (65.0 degrees C) Storage
Humidity: 10% to 90% Non-condensing Relative Humidity

Cisco VIP4-50 Physical Characteristics:
Shipping Dimensions: 4.5 Height x 22.25 Width x 22.5 Depth
Shipping Weight: 5 lb
