NM-16AM

Manufacturer Part#: Cisco NM-16AM
NM-16AM Cisco Module

NM-16AM - Cisco - Modem (analog) - plug-in module - 33.6 Kbps / 16 analog port(s)

In Stock & Ready to Ship

NM-16AM 16-port integrated analog modem network module provides support for basic dial service via RJ-11 connectors. It allows up to 16 remote analog modem users to connect via internal V.34 modems at speeds of up to 33.6 kbps.

Cisco NM-16AM General Information
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Name: Network Module
Product Type: Network Module

Cisco NM-16AM Interfaces/Ports
Interfaces/Ports: 16 x Modem WAN
Interfaces/Ports Details: 16 x RJ-11 Modem WAN

Cisco NM-16AM Media & Performance
Connectivity Media: Shielded Cable
Data Transfer Rate: 33.6Kbps

Cisco NM-16AM Management & Protocols
Management: Network management:
•Centralized management of multiple Cisco 2600, 3600 and 3700 with CiscoWorks
•In-band and out-of-band management via TCP/IP and SNMP, including Management Information Base II (MIB II) and other extensions, over TCP/IP
•TCP/IP addresses can be assigned via Dynamic Host Configuration Protocol (DHCP), per user, via an internal address pool, or selected remotely
•Maintains a detailed activity log for accounting, billing, and troubleshooting
•Advanced management using the (optional) MMTL
•Ability to download image and configuration across routers

Cisco NM-16AM Controls/Indicators
Status Indicators:
Network module status indicator
Network module status indicator

Cisco NM-16AM Environmental Conditions
Temperature: 32 degrees F (0.0 degrees C) to 104 degrees F (40.0 degrees C) Operating
Temperature: -13 degrees F (-25.0 degrees C) to 158 degrees F (70.0 degrees C) Storage
Humidity: 5% to 95% Relative Humidity

Cisco NM-16AM Physical Characteristics
Dimensions: 1.55 Height x 7.1 Width x 7.2 Depth
Shipping Dimensions: 9.5 Height x 13.5 Depth
Weight: 2 lb Maximum
Shipping Weight: 3 lb
