HWIC-AP-G-J

Manufacturer Part#: Cisco HWIC-AP-G-J
HWIC-AP-G-J Cisco Wireless Module

HWIC-AP-G-J - High Speed Wan Interface Card IEEE 802.11b/g - 54Mbps - Wireless Module

HWIC-AP 802.11G is Wireless LAN interface card in the HWIC (High-Speed WAN Interface Card) form factor providing integrated Access Point functionality in the Cisco 1800 (Modular), Cisco 2800, and Cisco 3800 Integrated Services Routers. Enterprise branch office and small-to-medium business customers can run concurrent services of Layer 3 routing, security, Layer 2 switching and now IEEE 802.11 wireless LAN functionality in a single platform. This combination offers ease of configuration, deployment, and management while delivering high performance, security and rich set of services.

Cisco HWIC-AP-G-J General Information:
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Name: HWIC-AP-G-J High Speed Wan Interface Card
Product Type: Wireless Module

Cisco HWIC-AP-G-J Wireless Specifications:
Wireless Technology: Wi-Fi - IEEE 802.11b/g
Antenna: 2 x 2.2dBi Swivel Dipole Antenna RP-TNC Connector
Antenna Range: 2000 ft@ 1 Mbps Outdoors
Antenna Range: 700 ft@ 11Mbps Outdoors
Antenna Range: 300 ft@ 54Mbps Outdoors
Antenna Range: 300 ft@ 1 Mbps Indoors
Antenna Range: 150 ft@ 11Mbps Indoors
Antenna Range: 80 ft@ 54Mbps Indoors
Frequency Band/Bandwidth: 2.41 GHz to 2.47 GHz IEEE 802.11b/g ISM Band Japan (TELEC)
Transmission Speed: 54Mbps
Transmission Speed Details: 54Mbps Auto-fallback IEEE 802.11g
Transmission Speed Details: 6Mbps IEEE 802.11g
Transmission Speed Details: 11Mbps Auto-fallback IEEE 802.11b
Transmission Speed Details: 1Mbps IEEE 802.11b
Transmit Power: 19 dBm IEEE 802.11b
Transmit Power: 17 dBm IEEE 802.11g

HWIC-AP-G-J Wireless Security:
TKIP
WAP2
802.1X
LEAP, PEAP, EAP-TLS, EAP-FAST, EAP-TTLS, EAP-SIM, EAP-MD5
Pre shared key (PSK)
MAC address and standard 802.11 authentication mechanisms
40/128 bits WEP
TKIP
WAP2
802.1X
LEAP, PEAP, EAP-TLS, EAP-FAST, EAP-TTLS, EAP-SIM, EAP-MD5
Pre shared key (PSK)
MAC address and standard 802.11 authentication mechanisms
40/128 bits WEP

HWIC-AP-G-J Modulation:
IEEE 802.11b/g:
•BPSK-6 & 9 Mbps
•QPSK-12 &18 Mbps
•16-QAM-24 & 36 Mbps
•64-QAM-48 & 54 Mbps

Cisco HWIC-AP-G-J Management & Protocols:
Security Features: MD5
Security Features: AES
Security Features: RADIUS

Cisco HWIC-AP-G-J Physical Characteristics:
Dimensions: 0.76 Height x 3.09 Width x 4.9 Depth
Weight: 0.32 lb - (hwic module and swivel dipole antennas)
