HWIC-AP-AG-E

Manufacturer Part#: Cisco HWIC-AP-AG-E
HWIC-AP-AG-E Cisco Wireless Module

HWIC-AP-AG-E - High Speed Wan Interface Card IEEE 802.11a/b/g - 54Mbps - Wireless Module

Cisco HWIC-AP 802.11A/B/G is Wireless LAN interface card in the HWIC (High-Speed WAN Interface Card) form factor providing integrated Access Point functionality in the Cisco 1800 (Modular), Cisco 2800, and Cisco 3800 Integrated Services Routers. Enterprise branch office and small-to-medium business customers can run concurrent services of Layer 3 routing, security, Layer 2 switching and now IEEE 802.11 wireless LAN functionality in a single platform. This combination offers ease of configuration, deployment, and management while delivering high performance, security and rich set of services.

Cisco HWIC-AP-AG-E General Information:
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Name: HWIC-AP-AG-E High Speed Wan Interface Card
Product Type: Wireless Module

Cisco HWIC-AP-AG-E Wireless Specifications:
Wireless Technology: Wi-Fi - IEEE 802.11a/b/g
Antenna: 2 x 2.2dBi Swivel Dipole Antenna RP-TNC Connector
Antenna Range: 2000 ft@ 1 Mbps Outdoors
Antenna Range: 80 ft@ 54Mbps Indoors
Antenna Range: 150 ft@ 11Mbps Indoors
Antenna Range: 300 ft@ 1 Mbps Indoors
Antenna Range: 300 ft@ 54Mbps Outdoors
Antenna Range: 700 ft@ 11Mbps Outdoors
Frequency Band/Bandwidth: 2.41 GHz to 2.47 GHz IEEE 802.11b/g ISM Band ETSI
Frequency Band/Bandwidth: 5.15 GHz to 5.35 GHz IEEE 802.11a ETSI
Transmission Speed: 54Mbps
Transmission Speed Details: 54Mbps Auto-fallback IEEE 802.11a/g
Transmission Speed Details: 1Mbps IEEE 802.11b
Transmission Speed Details: 11Mbps Auto-fallback IEEE 802.11b
Transmission Speed Details: 6Mbps IEEE 802.11a/g
Transmit Power: 20 dBm IEEE 802.11b
Transmit Power: 16 dBm IEEE 802.11a
Transmit Power: 17 dBm IEEE 802.11g

HWIC-AP-AG-E Wireless Security:
TKIP
WAP2
802.1X
LEAP, PEAP, EAP-TLS, EAP-FAST, EAP-TTLS, EAP-SIM, EAP-MD5
Pre shared key (PSK)
MAC address and standard 802.11 authentication mechanisms
40/128 bits WEP
TKIP
WAP2
802.1X
LEAP, PEAP, EAP-TLS, EAP-FAST, EAP-TTLS, EAP-SIM, EAP-MD5
Pre shared key (PSK)
MAC address and standard 802.11 authentication mechanisms
40/128 bits WEP

HWIC-AP-AG-E Modulation:
IEEE 802.11a:
•DBPSK-1 Mbps
•DQPSK-2 Mbps
•CCK-5.5 & 11 Mbps
•BPSK-6 & 9 Mbps
•QPSK-12 &18 Mbps
•16-QAM-24 & 36 Mbps
•64-QAM-48 & 54 Mbps

IEEE 802.11b/g:
•BPSK-6 & 9 Mbps
•QPSK-12 &18 Mbps
•16-QAM-24 & 36 Mbps
•64-QAM-48 & 54 Mbps

Cisco HWIC-AP-AG-E Management & Protocols:
Security Features: RADIUS
Security Features: AES
Security Features: MD5

Cisco HWIC-AP-AG-E Physical Characteristics:
Dimensions: 76 Height x 3.09 Width x 4.9 Depth
Weight: 0.36 lb - (hwic module and swivel dipole antennas)

Cisco HWIC-AP-AG-E Supported Platforms:
•Cisco 1841
•Cisco 2801
•Cisco 2811
•Cisco 2821
•Cisco 2851
•Cisco 3825
•Cisco 3845
