CISCO2651XM-V-CCME

Manufacturer Part#: Cisco  CISCO2651XM-V-CCME
CISCO2651XM-V-CCME Cisco 2600 Series Multiservice Router Platform

CISCO2651XM-V-CCME - Cisco2651Xm,48-Phone Ccme,30-Chan Digital Dsp,128D/32F

Cisco CISCO2651XM-V-CCME Media & Performance:
Distance Support: 328 ft UTP
Forwarding/Filtering Rate: 40Kpps

Cisco CISCO2651XM-V-CCME I/O Expansions:
Number of Expansion Slots: 4
Expansion Slots: (1 Total) AIM
Expansion Slots: (1 Total) Network Module
Expansion Slots: (2 Total) WIC
Modules: AIM-ATM-VOICE-30

Cisco CISCO2651XM-V-CCME Management & Protocols:
Management:
SNMP
RMON
SNMP
RMON

Protocols: RSVP
Protocols: TCP/IP
Protocols: AAL2
Protocols: AAL5

Cisco CISCO2651XM-V-CCME Processor & Chipset:
Processor: 1 x Motorola PowerQUICC MPC860 80MHz

Cisco CISCO2651XM-V-CCME Memory:
Standard Memory: 256MB
Maximum Memory: 256MB
Memory Technology: DRAM
Flash Memory: 32 MB

Cisco CISCO2651XM-V-CCME Controls/Indicators:
Controls: Power Switch
Status Indicators:
Front-Panel LEDs:
•POWER
•RPS
•ACTIVITY

Cisco CISCO2651XM-V-CCME Software:
Operating System:
Cisco 2600 Ser IOS SP SERVICES
Cisco 2600 Ser IOS SP SERVICES

Cisco CISCO2651XM-V-CCME Power Description:
Input Voltage: 110V AC
Input Voltage: 220V AC
Input Voltage Range: 100V AC to 240V AC
Input Voltage Range: 12V DC
Input Voltage Range: -12V DC
Input Voltage Range: 5V DC
Input Current: 9.5A @ 5V
Input Current: 1.5A
Input Current: 0.5A @ -12V
Input Current: 1.2A @ 12V
Frequency: 50 Hz or 60 Hz
Power Consumption: 50W Maximum
Power Source: Power Supply

Cisco CISCO2651XM-V-CCME Environmental Conditions:
Temperature: 32 degrees F (0.0 degrees C) to 104 degrees F (40.0 degrees C) Operating
Temperature: -40 degrees F (-40.0 degrees C) to 158 degrees F (70.0 degrees C) Storage
Humidity: 5% to 95% Non-condensing Relative Humidity Operating
Altitude: 6500 ft Maximum Operating
Thermal Dissipation: 260 BTU/h

Cisco CISCO2651XM-V-CCME Physical Characteristics:
Compatible Rack Unit: 1U
Form Factor: Rack-mountable
Form Factor: Desktop
Form Factor: Wall-mountable
Dimensions: 1.69 Height x 17.5 Width x 11.8 Depth
Shipping Dimensions: 11 Height x 20 Width x 23 Depth
Weight: 10.25 lb
