CISCO1841

Manufacturer Part#: Cisco CISCO1841
CISCO1841 Cisco 1800 Series Router

CISCO1841 - Integrated Services Router - 2 x 10/100Base-TX LAN, 1 x USB

Cisco 1841 Integrated Services Router is part of the Cisco 1800 Integrated Services Router Series which complements the Integrated Services Router Portfolio. The Cisco 1841 router features secure, fast, and high-quality delivery of multiple, concurrent services for small-to-medium-sized businesses and small enterprise branch offices. The Cisco 1841 router offers embedded hardware-based encryption enabled by an optional Cisco IOS Software security image; further enhancement of VPN performance with an optional VPN acceleration module; an intrusion prevention system (IPS) and firewall functions; interfaces for a wide range of connectivity requirements, including support for optional integrated switch ports; plus sufficient performance and slot density for future network expansion and advanced applications as well as an integrated real-time clock.

Cisco CISCO1841 General Information:
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Series: 1800
Product Name: 1841 Router
Product Type: Integrated Services Router

Cisco CISCO1841 Interfaces/Ports:
Number of Ports: 2
Fast Ethernet Port: Yes
Interfaces/Ports: 2 x RJ-45 10/100Base-TX LAN
Interfaces/Ports: 1 x Auxiliary Management
Interfaces/Ports: 1 x Console Management
Interfaces/Ports: 1 x USB

Cisco CISCO1841 I/O Expansions:
Number of Expansion Slots: 3
Expansion Slots: (2 Total) Expansion Slot
Expansion Slots: (1 Total) AIM

Cisco CISCO1841 Management & Protocols:
Management:
Cisco Router and Security Device Manager (SDM)
Command-Line Interface (CLI)
CiscoWorks
Cisco AutoInstall
Simple Network Management Protocol (SNMP)
Cisco Router and Security Device Manager (SDM)
Command-Line Interface (CLI)
CiscoWorks
Cisco AutoInstall
Simple Network Management Protocol (SNMP)

Protocols: TCP/IP
Protocols: SNMP

Cisco CISCO1841 Memory:
Standard Memory: 128MB
Maximum Memory: 384MB
Memory Technology: DRAM
Flash Memory: 32 MB

Cisco CISCO1841 Software:
Operating System:
Cisco 1841 IOS IP BASE
Cisco 1841 IOS IP BASE

Cisco CISCO1841 Power Description:
Input Voltage: 220V AC
Input Voltage: 110V AC
Input Voltage Range: 100V AC to 240V AC
Input Current: 1.5A

Cisco CISCO1841 Power Description:
Frequency: 50 Hz or 60 Hz
Power Consumption: 50W Maximum
Power Source: Power Supply

Cisco CISCO1841 Environmental Conditions:
Temperature: 32 degrees F (0.0 degrees C) to 104 degrees F (40.0 degrees C) Operating
Temperature: -4 degrees F (-20.0 degrees C) to 149 degrees F (65.0 degrees C) Non-operating
Humidity: 5% to 95% Non-condensing Non-operating
Humidity: 10% to 85% Non-condensing Operating
Thermal Dissipation: 153 BTU/h

Cisco CISCO1841 Physical Characteristics:
Form Factor: Desktop
Form Factor: Wall-mountable
Dimensions: 1.73 Height x 13.5 Width x 10.8 Depth
Dimensions: 1.87 Height x 13.5 Width x 10.8 Depth
Weight: 6.2 lb
Weight: 6 lb
