AIR-PI21AG-W-K9

Manufacturer Part#: Cisco AIR-PI21AG-W-K9
AIR-PI21AG-W-K9  Cisco Wi-Fi Adapter

AIR-PI21AG-W-K9 - 802.11a/b/g Low Profile PCI Adapter; Rest of World Cnfg

AIR-PI21AG-W-K9 General Information:
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Line: Aironet
Product Name: Aironet 802.11a/b/g Wireless NIC
Product Type: Wi-Fi Adapter

Cisco AIR-PI21AG-W-K9 Technical Information:
Wi-Fi Standard: IEEE 802.11a/b/g
ISM Band: Yes

Cisco AIR-PI21AG-W-K9 Technical Information:
UNII Band: Yes
ISM Minimum Frequency: 2.4 GHz
ISM Maximum Frequency: 2.49 GHz
UNII Minimum Frequency: 5.15 GHz
UNII Maximum Frequency: 5 GHz
Number of Antennas: 1
Antenna Gain: 1 dBi
Antenna Type: Dual Band Antenna
Indoor Antenna Range: 410 '
Outdoor Antenna Range: 2000 '
Wireless Transmission Speed: 54 Mbps

Cisco AIR-PI21AG-W-K9 Interfaces/Ports:
Host Interface: PCI

Cisco AIR-PI21AG-W-K9 Management & Protocols:
Management:
Cisco Aironet Desktop Utility
System Tray Utility
Client Administration Utility
Cisco Aironet Desktop Utility
System Tray Utility
Client Administration Utility

Cisco AIR-PI21AG-W-K9 Controls/Indicators:
Status Indicators:
Status (green)
Activity (amber)
Status (green)
Activity (amber)

Cisco AIR-PI21AG-W-K9 Power Description:
Input Voltage: 3.3 V 0.3V
Input Current: 203 mA Standby IEEE 802.11g
Input Current: 282 mA Receive IEEE 802.11g
Input Current: 554 mA Transmit IEEE 802.11a
Input Current: 530 mA Transmit IEEE 802.11g
Input Current: 203 mA Standby IEEE 802.11b
Input Current: 327 mA Receive IEEE 802.11b
Input Current: 539 mA Transmit IEEE 802.11b
Input Current: 318 mA Receive IEEE 802.11a
Input Current: 203 mA Standby IEEE 802.11a

Cisco AIR-PI21AG-W-K9 Environmental Conditions:
Temperature: 0 degrees C (32.0 degrees F) to 70 degrees C (158.0 degrees F) Operating
Temperature: 0 degrees C (32.0 degrees F) to 85 degrees C (185.0 degrees F) Non-operating
Humidity: 10% to 90% Non-condensing
