AIR-AP1232AG-A-K9

Manufacturer Part#: Cisco AIR-AP1232AG-A-K9
AIR-AP1232AG-A-K9 - Cisco Wireless Points (AP)

AIR-AP1232AG-A-K9 - CISCO AIRONET 1230AG - WAP-802.11(B,A,G)

Cisco Aironet 802.11a/b/g Access Point deliver the versatility, high capacity, security, and enterprise-class features demanded by WLAN customers. This IEEE 802.11a/b/g access points are designed specifically for challenging RF environments such as factories, warehouses, and large retail establishments that require theantenna versatility associated with connectorized antennas, a rugged metal enclosure, and a broad operating temperature range

 AIR-AP1232AG-A-K9 Interfaces/Ports:
Fast Ethernet Port: Yes
Interfaces/Ports: RJ-45 10/100Base-TX Uplink

Cisco AIR-AP1232AG-A-K9 Media & Performance:
Connectivity Media: 10/100Base-TX Twisted Pair
Data Transfer Rate: 10Mbps Ethernet
Data Transfer Rate: 100Mbps Fast Ethernet
 AIR-AP1232AG-A-K9 Processor & Chipset

Processor: IBM PowerPC405 200MHz

Cisco AIR-AP1232AG-A-K9 Memory:
Memory: 8MB Flash Memory
Memory: 16MB RAM

Cisco AIR-AP1232AG-A-K9 Controls/Indicators:
Status Indicators:
Three indicators on the top panel report Ethernet activity and status, device operating status, and radio activity and status
Three indicators on the top panel report Ethernet activity and status, device operating status, and radio activity and status

Cisco AIR-AP1232AG-A-K9 Power Description:
Input Voltage: 220 V AC
Input Voltage: 48 V DC
Input Voltage: 110 V AC
Input Voltage Range: 90V AC to 240V AC
Power Consumption: 11W Maximum
Power Source: Power Supply

Cisco AIR-AP1232AG-A-K9 Environmental Conditions:
Temperature: -20 degrees C (-4.0 degrees F) to 50 degrees C (122.0 degrees F)
Humidity: 10% to 90% Non-condensing

Cisco AIR-AP1232AG-A-K9 Physical Characteristics:
Dimensions: 1.66 Height x 6.56 Width x 7.23 Depth
Weight: 1.73 lb
