Product Description
Manufacturer Part#: Cisco AIR-ANT5160V-R
AIR-ANT5160V-R Cisco Antenna
AIR-ANT5160V-R - 5GHz 6dBi Omni Antenna w/RP-TNC connector
The antenna is a ruggedized high-performance colinear antenna that operates in the 5-GHz frequency range and is designed for use in large rooms or vaulted areas where extended coverage is needed. The antenna is designed to be used indoors or outdoors and can be mounted on a mast.
Cisco AIR-ANT5160V-R General Information:
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Line: Aironet
Product Name: Aironet 6-dBi Omnidirectional Antenna
Product Type: Omni-directional Antenna
Cisco AIR-ANT5160V-R Technical Information:
Antenna Range: 92 ft @ 54Mbps Indoor Approximate
Antenna Range: 822 ft @ 6Mbps Indoor Approximate
Frequency: 5.15 GHz to 5.88 GHz
Gain: 6 dBi
Polarization: Linear
Beamwidth: 17degrees E-Plane
Beamwidth: 360degrees Horizontal Plane
Survival Wind Speed: 125 M/h
VSWR: 2:1
Cable Length: 3 ft
Cisco AIR-ANT5160V-R Interfaces/Ports:
Connectors: 1 x RP-TNC
Cisco AIR-ANT5160V-R Environmental Conditions:
Temperature: -22 degrees F (-30.0 degrees C) to 158 degrees F (70.0 degrees C) Operating
Temperature: -40 degrees F (-40.0 degrees C) to 185 degrees F (85.0 degrees C) Storage
Cisco AIR-ANT5160V-R Physical Characteristics:
Dimensions: 1 Diameter x 11.5 Length
AIR-ANT5160V-R Cisco Antenna
AIR-ANT5160V-R - 5GHz 6dBi Omni Antenna w/RP-TNC connector
The antenna is a ruggedized high-performance colinear antenna that operates in the 5-GHz frequency range and is designed for use in large rooms or vaulted areas where extended coverage is needed. The antenna is designed to be used indoors or outdoors and can be mounted on a mast.
Cisco AIR-ANT5160V-R General Information:
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Line: Aironet
Product Name: Aironet 6-dBi Omnidirectional Antenna
Product Type: Omni-directional Antenna
Cisco AIR-ANT5160V-R Technical Information:
Antenna Range: 92 ft @ 54Mbps Indoor Approximate
Antenna Range: 822 ft @ 6Mbps Indoor Approximate
Frequency: 5.15 GHz to 5.88 GHz
Gain: 6 dBi
Polarization: Linear
Beamwidth: 17degrees E-Plane
Beamwidth: 360degrees Horizontal Plane
Survival Wind Speed: 125 M/h
VSWR: 2:1
Cable Length: 3 ft
Cisco AIR-ANT5160V-R Interfaces/Ports:
Connectors: 1 x RP-TNC
Cisco AIR-ANT5160V-R Environmental Conditions:
Temperature: -22 degrees F (-30.0 degrees C) to 158 degrees F (70.0 degrees C) Operating
Temperature: -40 degrees F (-40.0 degrees C) to 185 degrees F (85.0 degrees C) Storage
Cisco AIR-ANT5160V-R Physical Characteristics:
Dimensions: 1 Diameter x 11.5 Length
