AIR-ANT2535SDW-R=

AIR-ANT2535SDW-R=

The Cisco AIR-ANT2535SDW-R= antenna is a dual-band, sector antenna designed for use with Cisco Aironet wireless access points and bridges. It operates in both the 2.4 GHz and 5 GHz frequency bands and provides high-gain directional coverage for wireless networks.

Specifications:

Frequency Range: 2400-2500 MHz, 5150-5850 MHz

Gain: 6 dBi (2.4 GHz), 8.5 dBi (5 GHz)

Polarization: Linear, Vertical

Beamwidth: 90°

VSWR: 2:1

Input Impedance: 50 ohms

Connector: RP-TNC

Dimensions: 241 mm x 63.5 mm x 32 mm

Weight: 358g

Environmental: Indoor/Outdoor

Mounting: Pole or Wall

Operating Temperature: -40°C to +85°C

Humidity: 5% to 95% non-condensing

The Cisco AIR-ANT2535SDW-R= antenna is designed for use in both indoor and outdoor environments and provides directional coverage in a 90-degree beamwidth. With high-gain in both the 2.4 GHz and 5 GHz frequency bands, it can improve signal strength and coverage in a variety of wireless network setups. The RP-TNC connector ensures compatibility with a variety of Cisco wireless devices, and pole or wall mounting options provide greater flexibility in deployment. Its rugged design enables operation in harsh environments with extreme temperatures and high humidity.
