Cisco AIR-ANT2524DW-R

AIR-ANT2524DW-R

The Cisco AIR-ANT2524DW-R is a dual-band, omnidirectional dipole antenna designed for use with Cisco Aironet wireless access points and bridges. It operates in both the 2.4 GHz and 5 GHz frequency bands, providing enhanced coverage and improved signal quality for wireless networks.

Specifications:

• Frequency Range: 2400-2500 MHz, 5150-5875 MHz
• Gain: 2 dBi
• Polarization: Linear, Vertical
• Beamwidth: 360° Horizontal, 38° Vertical
• VSWR: 2:1
• Input Impedance: 50 ohms
• Connector: RP-TNC
• Dimensions: 163 mm x 13 mm x 13 mm
• Weight: 36g
• Environmental: Indoor
• Mounting: Ceiling, Wall, or Mast
• Operating Temperature: -20°C to +70°C
• Humidity: 5% to 95% non-condensing

The Cisco AIR-ANT2524DW-R antenna is a compact, low-profile solution for enhancing wireless coverage in indoor environments. With dual-band support and omnidirectional coverage, it provides excellent flexibility for a wide range of deployments. The antenna can be mounted on a ceiling, wall, or mast, and the RP-TNC connector ensures compatibility with a variety of Cisco wireless devices. Its compact size and unobtrusive design make it an attractive solution for environments where aesthetics are a consideration.
