AIR-ANT2410Y-R

Cisco AIR-ANT2410Y-R

Cisco 2.4 GHz 10dBi Yagi with RP-TNC Connector

NEW SEALED, CISCO FACTORY SEALED

Ready Stock, real time listings, real pictures

The AIR-ANT2410Y-R antenna is a high-gain yagi directional antenna designed to improve the performance of wireless networks operating on the 2.4 GHz frequency band. It is compatible with Cisco Aironet wireless access points, bridges, and other devices.

Specifications:

Frequency Range: 2400-2484 MHz

Gain: 10 dBi

Polarization: Linear, Vertical

Beamwidth: 35° Horizontal, 31° Vertical

VSWR: 2.0:1

Input Impedance: 50 ohms

Connector: RP-TNC

Dimensions: 1219 mm x 25 mm x 22 mm

Weight: 560g

Environmental: Indoor/Outdoor

Mounting: Pole or Wall

Operating Temperature: -40°C to +85°C

Humidity: 5% to 95% non-condensing

The AIR-ANT2410Y-R antenna is designed for use in both indoor and outdoor environments and can be mounted on a pole or wall for optimal coverage. With a high-gain of 10 dBi, it provides increased signal strength and better coverage compared to lower-gain antennas. The RP-TNC connector enables easy installation and compatibility with a wide range of Cisco wireless devices.
